Water

Cabading Reservoir and Booster Pump Station

Location
Antipolo City, Rizal, Philippines
Value
Php 1.4 billion
Client
Manila Water Company, Inc.
Status
Completed

About the project

Manila Water Company, Inc. (MWCI) provides water and wastewater services to the East Zone of Metro Manila. As part of MWCI’s commitment to providing quality water services, Cabading 3ML Reservoir and 80MLD Booster Station was undertaken to deliver water from Calawis Water Treatment Plant to the province of Rizal and nearby areas. The project involved the construction of a 3-million-liter reinforced concrete reservoir and an 80 million liters per day (MLD) pumping station.

Project scope

Design and construct of reservoir with a capacity of 3 million liters

A pumping station with a discharge capacity of 80 MLD up to 300 MLD

Pipelaying of 1600mm PN16 inlet pipe and 160mm PN25 discharge line with all necessary fittings and appurtenances

Slope protection as part of site development including the terrain of its location

Design, procurement, and installation of hydro-mechanical equipment

Automation of valves and other appurtenances
